VLAND 65A RV Main Board Smart Charging Upgrade Part for WFCO Power Center WF-9865-MBA
WF-9865-MBA 65 Amp RV Power Center Main Board Assembly
The WF-9865-MBA is a high-power main board for WFCO 9800 series power centers, delivering 65A DC power to support large RV electrical systems, high-wattage appliances and high-capacity battery banks.
Core Features
- 65A High-Output Design: Provides 65 Amps continuous DC power (900W), ideal for full-time RVs, toy haulers and RVs with multiple high-power devices like air conditioners and microwaves.
- Intelligent Battery Charging: Auto-detects LiFePO4, AGM, flooded and gel batteries, featuring 4-stage smart charging (bulk/absorption/float/maintenance) to optimize battery performance and extend service life.
- Comprehensive Safety Protection: Equipped with overcurrent, reverse polarity, over-temperature and surge protection, fully compliant with UL 458, RVIA and NEC safety standards for reliable operation.
- High-Efficiency Conversion: Boasts ≥85% power conversion efficiency, reducing energy loss and heat generation for stable performance in harsh RV environments, including off-grid use.
- Easy Drop-In Installation: Direct replacement for WF-9865 power center main boards, requiring only basic tools and 15 minutes for installation without any wiring modifications.
- Universal Input Compatibility: Accepts 90-130V AC input (50/60Hz), compatible with global power sources, making it suitable for international RV travel and diverse power supply scenarios.
Compatibility & Replacement
- Direct replacement for WF-9865 RV power center main boards
- Backward compatible with WF-9855 power centers (ideal for high-power upgrades)
- Fits all WFCO 9800 series power centers (9835, 9845, 9855, 9865)
- Replaces Parallax 7165/7155/7145 main boards with the included adapter
Warranty Service
Warranty Information
1-year limited manufacturer's warranty provided by WFCO Technologies, LLC.
This warranty covers defects in materials and workmanship, and includes free technical support throughout the warranty period.
Important Notes
- Disconnect AC power and battery terminals before installation to prevent electrical shocks or short circuits.
- When upgrading from 55A to 65A, ensure RV DC wiring is at least 2 AWG to support continuous 65A current and avoid overheating.
- Recommended for lithium battery banks of 200Ah or larger, as well as RVs with multiple high-wattage appliances running simultaneously.
- Do not modify the board's circuitry; any unauthorized modifications will void the 1-year limited warranty.
